| Place of Origin: | China |
|---|---|
| Brand Name: | Jikong |
| Model Number: | JK-B2A8S-20P |
| Minimum Order Quantity: | 1 pieces |
| Price: | 15USD/pcs |
| Packaging Details: | Carton |
| Delivery Time: | 15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/month |
| Equalizing Current: | 2A | Qualification Method: | Relay Port |
|---|---|---|---|
| Overcurrent Protection （ Adjustable ）: | 10~500A | Voltage Acquisition Accuracy: | ±5mV |
| Bluetooth Function: | Supports Android, IOS, And HarmonyOS | Charge And Discharge Control Port: | 12V (comes With 12) V Electric Relay ） |
| Display Interface: | Have | Products Status: | Stock |
| Operation System: | Win/Android/Bluetooth |
| Qualification | Productmodel | |
| B2A25S-XP | B2A4S-XP(12Vbattery) | |
| TernaryStringNumber | 5~25 | (Customizable) |
| Lithiumironseriesnumber | 6～25 | (Customizable) |
| Titaniumacidstringnumber | 9~25 | |
| Chargeanddischargecontrolport | 12V(comeswith12) | Velectricrelay) |
| Equalizingcurrent | 2A | |
| EquilibriumMethod | ActiveEquilibrium | |
| Qualificationmethod | Relayport | |
| CurrentAcquisitionInterface | Shuntdevice(500A,75mV);largercurrentscanbehandledbyadifferentshuntdevice. | |
| Overcurrentprotection | 10~500A | |
| (adjustable) | ||
| OtherInterfaces | ChoosebetweenRS485orCAN;CANisstandard. | |
| (custommade) | ||
| DisplayInterface | Have | |
| Maximumchargeanddischarge | Therequirementscanbeadjustedasneeded. | |
| current | ||
| Single-cellvoltagerange | 1~5V | |
| Voltageacquisitionaccuracy | ±5mV | |
| Overcharge/Overdisch- | Adjustablefrom1.2to4.35V | |
| argeProtectionVoltage | ||
| Overcharge/Overdisch- | Adjustablefrom1.2to4.35V | |
| argeRecoveryVoltage | ||
| Overcurrentreleasetime | Adjustablefrom2to120S | |
| Numberoftemperaturemeasurem- | 3 | |
| ents | ||
| TemperatureProtection | Have | |
| Coulombmeter | Have | |
| Bluetoothfunction | SupportsAndroid,iOS,andHarmonyOS | |
