| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | Barway |
| Price: | $55.00/pieces 1-199 pieces |
| Packaging Details: | neutral packing |
| Private Mold: | NO | Products Status: | Stock |
|---|---|---|---|
| Type: | Barcode Scanner | Scan Element Type: | CMOS |
| Colour Depth: | 32 Bit | Interface Type: | Usb, Blue-tooth |
| Optical Resolution: | 5mil | Scan Speed: | 240 In/s |
| Warranty(Year): | 1-Year | After-sales Service: | Others, Call Center And On-line Technical Support |
| Software Development Kit (SDK): | Yes | Product Name: | 2D Wireless Barcode Scanner |
| Resolution: | 640 * 480 | Bit Error Rate: | 1 / 5 Million |
| Cable Standard: | 0.8m | Battery Charging Time: | 2.5h |
| Size: | 90mm * 30MM * 21mm | Standby Current: | 0ma |
| Battery Working Time: | 4h | Lithium Battery: | 800mA |
| Charging Mode: | Type Charging Line, Plug-in Direct Charging | ||
| High Light: | 2D Portable Barcode Scanner,32Bit Portable Barcode Scanner,640x480 Bluetooth QR Code Scanner |
||
|
Performance Parameter
|
|
|
|
|||
|
Image sensor
|
617nm led aiming light, white LED illumination light
|
|
|
|||
|
Decoding capability
|
1D: code128ean-13 / isbnisnncode32ean-8, UPC-A
UPC-E,UCC/EAN-128Code39CodabarCode93,
Interleaved2of5. Industrial2of5/Stander2of5/IATA2of5 Matrix2of5Code11MSIPlesseyUKGS1DataBar. GS1
DataBarLimitGS1DataBarExpand,Datalogic2of5.
2D: QRcode, datamatrixpdf417, MicroPDF417, aztecode, direct transmission to Chinese
|
|
|
|||
|
Resolution
|
640 * 480
|
|
|
|||
|
Trigger mode
|
manual scanning / continuous scanning / automatic induction scanning scanning angle: angle 360 ° elevation ± 55 ° deflection ± 55
scanning accuracy: ≥ 5MIL contrast: ≥ 20%
|
|
|
|||
|
Scanning depth of field
|
ean1325-150mm (13mil90% PCs); QR 10-120mm (15mil30 bytes); PDF14730-110mm (667mil30 bytes)
|
|
|
|||
|
Bit error rate
|
1 / 5 million
|
|
|
|||
|
Wireless communication mode
|
paired mobile BT device: BT BLE4.0 wireless transmission distance: 20m (open)
|
|
|
|||
|
Inventory storage mode
|
offline storage mode: automatically store data when the scanning gun leaves the connection range, and the storage capacity is
512000 characters
|
|
|
|||
|
Physical Parameters
|
|
|
|
|||
|
Size
|
90mm * 30MM * 21mm (L x W x H)
|
Material
|
ABS+PC
|
|||
|
Cable standard
|
0.8m
|
|
|
|||
|
Environmental Parameters
|
|
|
|
|||
|
Working temperature
|
-20 ℃ ~ 50 ℃ storage temperature: - 40 ℃ ~ 70 ℃
|
|
|
|||
|
Relative humidity
|
5% ~ 95% (non condensing)
|
|
|
|||
|
Seismic capacity
|
it can withstand multiple 12m free falls
|
|
|
|||
|
Electrical Parameters
|
|
|
|
|||
|
Voltage
|
dc5v5%
|
Standby current
|
0ma
|
|||
|
Battery charging time
|
2.5h
|
Battery working time
|
4h
|
|||
|
Lithium battery
|
800mA
|
|
|
|||
|
Charging mode
|
type charging line, plug-in direct charging
|
|
|
|||
|
Maximum working current (maximum)
|
200mA
|
|
|
|||
