| Place of Origin: | Jiangsu, China |
|---|---|
| Price: | $839.00/pieces |
| Private Mold: | Yes | Products Status: | Stock |
|---|---|---|---|
| Interface Type: | Usb | Max Paper Size: | ISO CR80 85.6mm X 54mm |
| Black Print Speed: | 3~5 S (single-sided) / 7~12 S (dual-sided) | Color Print Speed: | 20 S (single-sided) / 42 S(dual-sided). |
| Max. Resolution: | 300dpi | Warranty(Year): | 1-Year |
| After-sales Service: | Return And Replacement | Style: | Black /colour |
| USE: | Card Printer | Magnetic Stripe: | ISO 7811 Tracks 1, 2 And 3 |
| After-sales Service:: | Repair | Weight: | 5.3 Kg (11.6 Lbs) |
| Printing Speed:: | 45 Sec /card - 80 Cards/hour | Interface: | USB |
| Printing Material: | Color Dye Film | ||
| High Light: | PVC ID Card Printer,S21 PVC ID Card Printer,S22 Single Side Printing Machine |
||
|
Model
|
S22 / Desktop Dual-sided Card Printer
|
Input Capacity
|
100 cards
|
||
|
Specifications
|
383 × 174 × 208 (mm), 6.8Kg
|
Output Capacity
|
50acrds
|
||
|
Print Speed
|
100-240V, 50-60Hz
|
Interfaces
|
USB & Ethernet
|
||
|
Power
|
100-240V, 50-60Hz
|
Memory
|
128M
|
||
|
Print Dimension
|
ISO CR80 (53.98*85.60mm), edge-to-edge printing
|
Print Resolution
|
300dpi*300dpi(Optional: 300dpi*600dpi)
|
||
|
Print Method
|
Dye sublimation
(Direct-to-card) |
Card Thickness
|
0.3-1.05mm
|
||
|
LCM Display
|
Chinese: 8 characters per line, 2 lines /
English: 16 characters per line, 4 lines / Multi-language |
Operation System
|
Driver: support Windows® XP/7/8/10 (32 or 64 bit), Linux, Unix. Card design software: ICARDE, support Windows® XP/7/8/10 (32 or 64 bit)
|
||
|
Card Material
|
PVC / Composite PVC / Other material upon request and validation
|
Storage Condition
|
Temp.: -5℃-70℃(23-158℉), 20%~70% RH non-condensing
|
||
|
Warranty
|
Card printer: 12 months (artificial damage excluded) / Print head: replace one for free within 1 year(artificial damage excluded)
|
Operating Condition
|
1. Regular running temp.: 15℃-30℃(59-86℉), 20%~65% RH non-condensing
2. Lowest / Highest running temp.: 0℃(32℉) / 40℃(104℉), 20%~65% RH non-condensing |
||
|
Certificates
|
CCC, FCC, CE, ROHS
|
|
|
||
