Private Mold: | NO | Products Status: | Stock |
---|---|---|---|
Interface Type: | Usb | Max Paper Size: | 4 Inch |
Black Print Speed: | 90mm/s | Color Print Speed: | Null |
Max. Resolution: | 384dots/line | Warranty(Year): | 1-Year |
After-sales Service: | Return And Replacement | Product Name: | XP460B Thermal Printer Express Waybill 100MM Thermal Barcode Printer |
Printing Method: | Thermal Line Printing | Interface: | USB+Bt |
Printing Support: | Labels And Receipts | Print Command: | ESC/P0S Command, TSPL, CP |
Printing Width: | Max. 108mm | IP54 Standard: | Support |
Battery: | 1200mAh Rechargeable Lithium | Support System: | Android+iOS+Windows |
Warranty: | 12 Months | ||
Highlight: | XP460B Thermal Printer,Barcode Self Adhesive Label Printer,100MM Thermal Barcode Printer |
Printing Features
|
|
|
Resolution
|
203DPI
|
|
Print method
|
Direct thermal
|
|
Max. print speed
|
152mm/s (6" mm/s)
|
|
Max. print width
|
108mm (4.25")
|
|
Max. print length
|
1778mm (70")
|
|
Media
|
|
|
Media type
|
Continuous, gap, black mark, fan-fold and punched hole
|
|
Media width
|
25.4-118mm (1.0" - 4.6")
|
|
Media thickness
|
0.06 - 0.25mm (2.36 - 9.8 mil)
|
|
Media core diameter
|
25.4 - 76.2mm (1" - 3")
|
|
Label length
|
10-1778mm (0.39" - 70")
|
|
Label roll capacity
|
127mm (5") OD (External diameter)
|
|
Performance Features
|
|
|
Processor
|
32-bit CPU
|
|
Memory
|
8MB Flash Memory/8MB SDRAM/Flash memory can be expanded Max. 4GB
|
|
Interface
|
Standard: USB TF card, Optional: Serial/LAN/Wi-Fi
|
|
Fonts/Graphics/Symbologies
|
|
|
Internal fonts
|
8 alpha-numberic bitmap fonts, Windows fonts are downloadable from software.
|
|
1D barcode
|
Code 39, Code 93, Code 128UCC, Code 128, subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN
and UPC 2(5) digits add-on, MSI, PLESSEY, OOSTNET, China POST |
|
2D barcode
|
PDF-417, Maxicode, DataMatrix, QR code
|
|
Rotation
|
0º, 90º, 180º, 270º
|
|
Emulaion
|
TSPL, EPL, ZPL, DPL
|
|
Physical Features
|
|
|
Dimension
|
189.67x147.78x219.22mm (WxHxD)
|
|
Weight
|
1.3kg
|
|
Reliability
|
|
|
Warranty
|
1 year
|
|
Print head
|
30km
|
|
Software
|
|
|
Driver
|
Windows / Android / Linux / Mac
|
|
SDK
|
Windows / Android / iOS
|
|
Power supply
|
|
|
Input
|
DC 24V/2.5A (Printer input: DC 24V/2.5A)
|
|
Output
|
DC 24V, 2.5A, 60W
|
|
Optionals
|
|
|
Factory options
|
①Serial ②LAN ③Wi-Fi ④BT ⑤Peeler ⑥RTC
|
|
Dealer options
|
①External paper roll holder and 1" paper roll
②Extension board for external paper roll holder
③Shipment waybill box |
|
Environmental Conditions
|
|
|
Operating temperature
|
5-40℃(41-104℉), Humidity: 25-85% non-condensing
|
|
Storage temperature
|
-40-60℃(-40-140℉), Humidity: 10-90% non-condensing
|
