Product Details:
|
| Private Mold: | Yes | Products Status: | Stock |
|---|---|---|---|
| Type: | Thermal, Thermal Printer | Style: | Color |
| Use: | Thermal Label Printer | Interface Type: | Usb |
| Max Paper Size: | 25.4 Mm ~ 115 Mm | Black Print Speed: | 152 Mm (6") / S |
| Color Print Speed: | Null | Max. Resolution: | 8 Dots/mm(203DPI) |
| Warranty(Year): | 1-Year | After-sales Service: | Return And Replacement, Repair, Call Center And On-line Technical Support |
| Interface: | USB; USB+BT (Option);USD+WIFI (Option) | Printing Width: | 25.4 Mm ~ 115 Mm |
| Dimension: | 215 Mm (L) X 178 Mm (W) X 155 Mm (H) | Input: | AC 110-240V |
| Weight: | 1.31 Kg | Media Type: | Continuous, Gap, Black Mark, Fan-fold And Punched Hole |
| Media Thickness: | 0.06~0.254 Mm (2.36~10mil) | ||
| High Light: | 4x6 Inch Thermal Shipping Label Printer,203DPI Bar Code Label Printer |
||
|
Model
|
XP-420B
|
|
|
Printing Features
|
|
|
|
Resolution
|
203 DPI
|
|
|
Printing method
|
Direct Thermal
|
|
|
Max.print speed
|
152 mm (6") / s Max.
|
|
|
Max.print width
|
108 mm (4.25”)
|
|
|
Max.print length
|
1778 mm
|
|
|
Media
|
|
|
|
Media type
|
Continuous, gap, black mark, fan-fold and punched hole
|
|
|
Media width
|
25.4 mm ~ 115 mm
|
|
|
Media thickness
|
0.06~0.254 mm (2.36~10mil)
|
|
|
Media core diameter
|
25.4 ~ 76.2 mm (1 "~ 3 ")
|
|
|
Label length
|
10 mm ~1778 mm
|
|
|
Performance Features
|
|
|
|
Processor
|
32-bit CPU
|
|
|
Memory
|
8MB Flash Memory, 8MB SDRAM, Flash memory can be expanded to Max. 4 GB
|
|
|
Interface
|
Standard version: USB Optional:Lan/WIFI/BT/TF card
|
|
|
Sensors
|
①Gap sensor
|
|
|
|
②Cover opening sensor
|
|
|
|
③Black mark sensor
|
|
|
Fonts/Graphics/Symbologies
|
|
|
|
Internal fonts
|
8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software.
|
|
|
1D bar code
|
Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E, EAN and
UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST,GS1 DataBar, Code 11 |
|
|
2D bar code
|
PDF-417, Maxicode, DataMatrix, QR code, Aztec
|
|
|
Rotation
|
0°,90°,180°,270°
|
|
|
Emulaion
|
TSPL,EPL,ZPL,DPL
|
|
|
Physical Features
|
|
|
|
Dimension
|
215 mm (L) x 178 mm (W) x 155 mm (H)
|
|
|
Weight
|
1.31 kg
|
|
|
Reliability
|
|
|
|
Warranty
|
One year
|
|
|
Print head life
|
30 km or first arrival first
|
|
|
Software
|
|
|
|
Driver
|
Windows/ Linux/ Mac
|
|
|
SDK
|
Windows/ Android/ iOS
|
|
|
Power supply
|
|
|
|
Input
|
AC 110-240V
|
|
|
Output
|
DC 24V 2.5A
|
|
|
Options
|
|
|
|
Factory Options
|
①Peeler ②Cutter ③RTC
|
|
|
Dealer Options
|
①External paper roll holder
|
|
|
|
②Paper roll spindle
|
|
|
|
③Extension board for external paper roll holder
|
|
|
Environmental Conditions
|
|
|
|
Operation environment
|
5 ~ 40°C(41~104°F),Humidity: 25 ~ 85% no condensing
|
|
|
Storage environment
|
-40 ~ 60°C(-40~140°F),Humidity: 10 ~ 90% no condensing
|
|
