| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | BW |
| Certification: | FCC, ce, GS, CSA, RoHS, SIG（BluetoothSIG) |
| Price: | $15.00/Pieces 1-9 Pieces |
| Packaging Details: | Foam wrap inside<br>Cardboard box parcel outside |
| Private Mold: | NO | Products Status: | Stock |
|---|---|---|---|
| Type: | Barcode Scanner | Scan Element Type: | CMOS |
| Colour Depth: | 32 Bit | Interface Type: | Usb, COM, PS/2 |
| Max Paper Size: | A4 | Optical Resolution: | >=5mil |
| Scan Speed: | 100/sec | Warranty(Year): | 1-Year |
| After-sales Service: | Return And Replacement, Others, Repair, Free Spare Parts, Onsite Training And Inspection, Call Center And On-line Technical Support | Application: | Store Inventory |
| Light Source: | Red LED | Interface: | USB2.0 |
| Scan Mode: | Auto Scan | Decode Capabilities: | 1D + 2D + QR Code |
| Color: | Balck | Scan Type: | 1D/2D/QR |
| Scan Angle: | Rotation 360 | Battery: | 2600mAh |
| Product Name: | Qr Code Scanner | ||
| High Light: | Handheld 2D Barcode Reader,Wireless 2D Barcode Reader,32 Bit 2d wireless barcode scanner |
||
|
Specification of Barcode Scanner
|
|
|
|
|||
|
Device type
|
2d Barcode scanner
|
|
|
|||
|
Scanning method
|
COMS
|
|
|
|||
|
Bit rate
|
1/5 million times
|
|
|
|||
|
Trigger mode
|
manual button trigger mode
|
|
|
|||
|
Transmission mode:
|
sweep and pass, inventory two modes
|
|
|
|||
|
Scanning angle
|
Field of view angle: horizontal 45°, vertical 34°
|
|
|
|||
|
Reading code system
|
2D:PDF417,QR Code,Data Matrix
1D:Code 128,UCC/EAN-128,AIM128,EAN-8,EAN-13,ISBN/ISSN,UPC-E,UPC-A,Interleaved 2 of 5,ITF-6,ITF-4,Matrix 2 of 5,Industrial 25,Standard 25,Code 39,Codabar,Code 93,Code 11,Plessey,MSI-Plessey,RSS-14,RSS-Limited,RSS-Expand |
|
|
|||
|
Accuracy
|
≥5mil
|
|
|
|||
|
Mechanical / electrical
|
|
|
|
|||
|
Protective design
|
Protection class (optional): IP42
|
|
|
|||
|
Electrostatic discharge
|
±15kV (air discharge),±8kV (direct discharge)
|
|
|
|||
|
How to prompt
|
Buzzer, LED indication
|
|
|
|||
|
Power supply
|
DC 5V±10% Current: operating: 62ma (typical), 115.5 mA (Max); standby: 33ma
|
|
|
|||
|
Power consumption
|
0.31W
|
|
|
|||
|
Other parameters
|
|
|
|
|||
|
Product size
|
101×68×146mm
|
|
|
|||
|
Product weight
|
115g
|
|
|
|||
|
Environmental parameters
|
Operating temperature: -20-50℃, storage temperature: -40-70℃ Relative humidity: 5-95% (non-condensing)
|
|
|
|||
|
Battery
|
Built-in Li battery, 3.7v/7800mAh
|
|
|
|||
|
Charging port
|
TYPE-C (5V-2.4A)
|
|
|
|||
|
NFC
|
Optional (M1 have; M1S haven't)
|
|
|
|||
